Purpose of this Document
Overview
API Description
API Example
Connector Registration
Appendix A – Resource Definition
The Identity Governance provisioning platform is designed with extensibility as a primary goal. Its primary strength is its ability to provision many diverse types of resources and services. To enable this strength, the ability to plug custom connectors into the platform without altering the core platform itself has been provided through the use of a defined application programming interface (API). This document describes this API, named the Provisioning Connector API, and how it interacts with the Identity Governance provisioning platform.
The Provisioning Connector API has been developed to provide the developers of custom connectors that can be used from the Identity Governance provisioning platform, or any other java-based provisioning platform that supports the same interface. It is expected that the provisioning platform itself will perform all of the operations needed to determine the operations and their parameters that are to be executed against resources. The connector itself will be responsible for executing those operations on the resource in whatever resource specific manner required. The interface between the platform and the connector used to implement this procedure is defined with this API.
There are eight operations that make up the interface between the provisioning platform and the connector, add, modify, delete, suspend, restore, change password, search, and test. Each of these operations, with the exception of suspend, restore, and change password, are defined in such a manner as to support the provisioning of any object supported on the resource, but typically provisioning systems today only focus on provisioning users. Because of the initial focus on user provisioning, the suspend, restore, and change password operations are key user-focused operations that provide convenience.
When performing these eight provisioning operations, some resources will require either asynchronous or synchronous communications. The Provisioning Connector API supports both modes of operation, but the custom connector implementation will be responsible for performing the communication with the resource itself.
The API consists of a set of java classes that provide the signatures that a connector must meet to be successfully integrated with a provisioning platform. These classes are focused on the interactions needed to communicate between the connector and the platform for the execution and confirmation of provisioning actions. These classes are designed to loosely couple the connector with the provisioning platform for possible portability between platforms. When implementing these actions, however, the use of additional platform specific API’s may become more valuable to provide a complete solution than the need of portability. For making use of the additional services provided by the Identity Governance provisioning platform, please reference the Identity Manager provisioning API reference documentation.
The Provisioning Connector API consists of a set of classes that define the interface between the provisioning platform and the provisioning connector. All of these classes can be found in the com.ibm.itim.remoteservices.provider and com.ibm.itim.remoteservices.exception packages. The com.ibm.itim.common package is also referenced for its definition of classes to represent attributes.
The focal class in the API is the ServiceProvider. The ServiceProvider holds the interface for the eight standard operations, and for all intent and purposes, represents the connector to the provisioning platform. Most of these operation interfaces can support both synchronous and asynchronous calls.
The choice of whether to operate synchronously or asynchronously is determined by the ServiceProvider implementation. The platform is made aware of this behavior by passing back a pending status (see the RequestStatus class) at the time of the call. The ServiceProvider will then inform the platform of the completion of the operation by using a Notifier. The Notifier is just one interface that can be used to communicate directly from the connector to the provisioning platform. The Notifier, and other platform interfaces, can be retrieved by using the InitialPlatformContext class.
The InitialPlatformContext provides ServiceProvider implementations an interface to obtain provisioning platform specific services in a platform independent manner. This will help enable portability between provisioning platforms. Besides the Notifier already mentioned, a DirContext instance can be obtained from the InitialPlatformContext which can be used by the connector to store and retrieve information in the provisioning platform’s directory (note: The term directory usually implies an LDAP directory to most people, but a given platform may implement the directory interface with any backend data store). Please see the Java Development Kit v1.3.1 API documentation for a more detailed description of the DirContext.
In addition to the InitialPlatformContext, when building a connector that is tailored for the Identity Governance provisioning platform, all other API’s listed in the Identity Manager API documentation may be used. These API’s may help a connector implementation to better integrate its capabilities with Identity Governance’s other services.
One of the prime functions of a connector is to provide the provisioning platform the ability to retrieve information from the managed resource or service. A search interface is provided by ServiceProvider to do this. The interface takes a SearchCriteria to direct the ServiceProvider as to what information the platform needs. This SearchCriteria will contain an LDAP search filter in RFC 2256 format and a search base to identify which entries should be returned. The matching results are returned in a SearchResults object, which is implemented as part of the ServiceProvider implementation. The ability to cancel a currently executing search is provided through the SearchResults interface. By defining only an interface for SearchResults, a connector implementation can provide for lazy retrieval and abort capabilities in a resource specific manner, if available.
Due to the diverse capabilities of some resources and services, some operations may not be supportable by some connectors. In situations where an operation cannot be implemented, the expected behavior of the ServiceProvider is to throw an UnsupportedOperationException. This exception can be found in the Java Development Kit v1.3.1 API documentation.
Please see the accompanying example code with this package.
To completely integrate the connector with the provisioning platform, that connector must somehow be registered with the platform so it knows when to invoke it. The integrate a connector with Identity Governance, the integration process has three main steps, register ServiceProvider implementation with the application server, define and register an LDAP schema to represent services and users associated with the connector, and define the behavioral properties of the connector.
To register the ServiceProvider implementation with the application server, all java classes that have been developed in the implementation must be placed in the application server’s classpath. Modifying the application server environment shared library for Identity Governance Lib can accomplish this.
In the Identity Governance platform, the resource or service that needs to be provisioned must first be instantiated and configured so that the platform can pass along resource instance specific properties to the connector to implement the provisioning operations. When users are provisioned on to this “service”, the user’s settings are represented as a user account object within the platform. For the platform to store and display the correct set of parameters for both the service and the user account instances, a proper LDAP schema must be defined for them. So, for example, to provision an NT domain server with a DAML based connector, an NT domain service class is defined in LDAP to hold the DAML protocol parameters and the domain name to be provisioned. Another LDAP class is defined to hold the NT user account information, such as groups and password. In addition to these base set of classes, any other information that can be retrieved from the connector, such as the existing groups on the NT domain server, must have a defined schema as well, so that Identity Governance can store them in its local directory once retrieved.
The final step in the registration process is to create and install a resource definition. This definition is an XML file that specifies the relationships between the connector and the schema classes defined, along with behavioral properties that are common to all instances of the connector. The behavioral properties can be properties that the platform uses to configure or communicate with the connector, such as the ServiceProviderFactory class name. They can also be properties that are used within the connector implementation and may be connector specific. The DTD for this file is listed in Appendix A. The platform behavioral properties that can be used are listed below.
The resource definition file should be named resource.def. That file, along with the DSML schema file, should be placed in a file directory with the same name as the service profile name (see the resource definition DTD) under the remoteservices file directory in the Identity Governance distribution. With this done, the config_remote_services script provided in the distribution can be run to register the information with the Identity Governance platform and the directory server.
For the newer ISDI based adapters the resource definition file is named service.def, and the prefered method to register the resource definition is to make a jar file of the directory that contains all of the resource definition files, and use the Identity Governance UI Configure System > Manage Service Types to import the jar file.
This appendix lists the resource definition DTD and the Identity Governance platform specific properties that can be used to instruct Identity Governance on how to interact with the connector. The DTD can also be found in the resource.dtd file.
<?xml version="1.0" encoding="UTF-8"?>
<!-- The Resource describes all the behavior and components that define a -->
<!-- connector. -->
<!ELEMENT Resource (SystemProfile, ServiceDefinition, AccountDefinition?)>
<!-- The SystemProfile describes the behavior of the connector through a set of -->
<!-- properties, some that are consumed by the platform and some consumed by -->
<!-- the connector. -->
<!ELEMENT SystemProfile (Name, Description?, BehaviorProperties?, ProtocolProperties?)>
<!ELEMENT Name (#PCDATA)>
<!ELEMENT Description (#PCDATA)>
<!-- Properties to describe the behavior that can be consumed by the platform and -->
<!-- the connector. Note: The name of the ServiceProviderFactory class must be -->
<!-- present. -->
<!ELEMENT BehaviorProperties (Property*)>
<!-- Properties to define the protocol parameters common to all instances of the -->
<!-- connector. Parameters that are specific to each instance (i.e., URLs, IP -->
<!-- addresses) are provided in the service schema. -->
<!ELEMENT ProtocolProperties (Property*)>
<!ELEMENT Property>
<!ATTLIST Property
Name CDATA #REQUIRED
Value CDATA #IMPLIED
>
<!-- The ServiceDefinition describes the representation of a service provisioned -->
<!-- by this connector. It also identifies the schema classes used to represent -->
<!-- the service and a user account on the service. -->
<!ELEMENT ServiceDefinition>
<!ATTLIST ServiceDefinition
ServiceProfileName CDATA #REQUIRED
ServiceClass CDATA #REQUIRED
AttributeName CDATA #REQUIRED
AccountClass CDATA #REQUIRED
AccoutProfileName CDATA #REQUIRED
Description CDATA #IMPLIED
>
<!-- The AccountDefinition describes the user account and how it integrates -->
<!-- with the provisioning platform. -->
<!ELEMENT AccountDefinition>
<!ATTLIST AccountDefinition
ClassName CDATA #REQUIRED
Description CDATA #IMPLIED
>The Identity Governance platform specific properties that should be included in the BehaviorProperties element are listed below. The description of each one can be found in the ServiceProviderInformation API documentation. Each property can be looked up using its API constant. Required properties are marked with an *.
| Property Name | API Constant |
| com.ibm.itim.remoteservices.ResourceProperties.PROTOCOL_MODE | PROTOCOL_MODE |
| com.ibm.itim.remoteservices.ResourceProperties.STORE_ACCOUNT_PASSWORD | STORE_ACCOUNT_PASSWORD |
| com.ibm.itim.remoteservices.ResourceProperties.FILTERING_NOT_SUPPORTED | FILTERING_NOT_SUPPORTED |
| *com.ibm.itim.remoteservices.ResourceProperties.SERVICE_PROVIDER_FACTORY | SERVICE_PROVIDER_FACTORY |
